Overview:

The Switch is a ZigBee-enabled inching/self-lock temperature smart switch that is compatible with different hubs. When the temperature of the environment falls within the range, it will automatically turn on or off the connected devices. It also supports timing turning on/off the appliances and supports presetting the range for temperature.

The ZigBee3.0 protocol gets the switch and ZigBee bridge to be paired in a quick way.
This item is a universal switch for your smart home system to remotely and automatically turn on/off any appliances by phone Tuya / Smart-life APP. The switch is safer to use in you home that is promised by the fire-proof and flame-retardant shell. Additionally, AES-128 encryption ensures the safety is extended to data device privacy, no worry about privacy disclosure of your device. It can be as a Zigbee router to help transmit the ZigBee signal to ensure a stable connection when multiple Zigbee devices are used for your home.

Parameters:

Input voltage : AC 85-250V, Micro USB 5V input.
Output: Signal output only, no voltage output.
Input current: Max 10A
Wireless Standard: Zigbee
Control mode: Mobile APP Tuya / Smart Life
Platform: for Android, iOS
Gang: 1
Support temperature sensor (not support humidity sensor now)
Smart Switch Size: 72*45*29 (mm)

Checklist before using the device

1) Your smartphone or tablet has been connected to a 2.4G WiFi capable of accessing the Internet (5G WiFi is not currently supported)
2) The mobile phone or tablet using the Android system must be an Android version above 4.0
3) If your wireless router has set MAC address filtering, please enter the router background and turn off the MAC filtering function
4) Must be used in conjunction with Zigbee gateway.You need to have a Zigbee gateway.Try to be close to the Zigbee gateway when pairing.

Two working modes

1. Self-locking: each channel can be turned on/off individually, and all channels can be turned on/off at the same time.

2. Inching mode: open a channel, the channel will automatically close after 1 seconds.

If you need to change the mode, you need to press the mode button

Note
It does not support Interlocking mode.

Features:

*App Support: Free iOS and for Android mobile App TUYA.
*Sync Status: Real-time device status provided to App.
*Real-time monitor: Monitor real-time temperature.
*Remote ON/OFF: Turn electrical devices on/off from anywhere, with high accuracy temperature waterproof sensor.
*Share Control: Control your smart home together with your family.
*Timing: Supports 8 enabled countdown/single/repeat timing tasks to turn on/off at specified time.
*Auto Mode: Set Auto mode to turn on/off at a specified temp. range.
*Manual Mode: Set manual mode to turn on/off immediately.
*Trigger Smart Scene: The temp. value works as smart scene trigger conditions to trigger on/off other TUYA devices.
*Voice Control: Compatible with "Amazon" Alexa, for Google Home, for Google Nest.
*Waterproof temperature sensor with stainless steel temperature probe, high accuracy, wide usage in daily life.
*RF Remote control: Turn on/off by 433MHz RF Remote indoors,Only support 433MHz Learning code.

Smart Temperature Control Switch

Set a fixed temperature, and the intelligent switch automatically controls the switch according to the temperature change.

Sensor Specifications:

Type: Waterproof temperature sensor
Probe: Stainless steel temperature probe
Temperature Measuring Range: -55℃~+125℃
Operating Voltage: 3.0-5.5V
Weight: 26g
Length: 1m

NOTE:

The sensor can only detect temperature, if you need to detect humidity, please prepare your own humidity sensor.

Include:

1 * Temperature Smart Switch
1 * Sensor
