SPECIFICATIONS

Advantage: Precision

Feature: Conveniently Operation

Function: extrusion

Keyword: Press Packing

Machine name: Carton Foaming Machine

Name: Carton Foaming Machine

Packaging Material: Paper,Wood

Packaging Type: Cartons,Bags

Packing material: Paper Bag

Packing speed: 20-25/min

Product name: Carton Box Erector Machine

Usage: Paper Waste

Voltage: 220v

application: Food,Beverage,Commodity

automatic grade: Semi-Automatic

brand name: hongle

core components: Motor

dimension(l*w*h): 60*60*135cm

driven type: Pneumatic

key selling points: Easy To Operate

machinery test report: Provided

place of origin: Henan, China

power: 75w

type: Other

video outgoing-inspection: Provided

warranty: 1 Year

Product Description

The carton pressure foaming machine is designed for the problems of bubbles, wrinkles and deformation on the bonding surface after the carton of the gluing machine is formed. Low efficiency does not guarantee accuracy. After
processing this machine, it not only guarantees the excellent characteristics and accuracy of high-end gift boxes, but also
reduces the human and financial resources. It can save 3-4 workers who scratch the carton. This machine is cheap and widely used. The advantage effect is more significant.
Widely used in jewelry boxes, shoe boxes, shirt boxes, underwear boxes, mobile phone boxes, moon cake boxes, tea boxes, wine boxes, and other various gift packaging boxes.

Size Information

Size Chart of This Design

model	HL-320	HL-400	HL-450
Minimum working size	50*50*40mm	50*50*40mm	60*60*40mm
Working size	320*320*80mm	400*400*100mm	450*450*120mm
weight	75kg	85kg	85kg
Machine size	600*600*1350mm	700*700*1400mm	800*600*1450mm
Use air pressure	4-8map	4-8map	4-8map
voltage	220v/50-60hz	220v/50-60hz	220v/50-60hz
Working speed	20-25/min	20-25/min	20-25/min
Down cylinder pressure	120-220kg	120-300kg	120-250kg
Four-sided cylinder pressure	80-125kg	100-160kg	100-160kg
