SPECIFICATIONS

Bag length: 60-200mm

Bag type: Pillow Bag Gusseted Bag Quad Seal Bag

Control System: Schneider PLC

Dosing: Auger Filler

Machine type: Automatic Bag Forming Filling Sealing Machine

Material: Stianless Steel

Measuring range: Max. 4000ml

Operation: Schneider Touch Screen

Packaging Material: Plastic,Paper,Metal,Glass,Wood

Packaging Type: Cartons,Cans,Bottles,Barrel,Stand-up Pouch,Bags,Film,Foil,Belt,Pouch,Case

Packing speed: 10-70 Bags/min

Product name: Granule Packing Machine

Voltage: 380

application: Food,Beverage,Commodity,Chemical,Machinery & Hardware,Apparel,Textiles

automatic grade: Automatic

core components: PLC,Engine,Bearing,Gearbox,Motor,Pressure Vessel,Gear,Pump

driven type: Electric

key selling points: Automatic

machinery test report: Provided

place of origin: Guangdong, China

power: 1.5kw

type: Other

video outgoing-inspection: Provided

Title goes here.

* Famous brand PLC control system, wide version touch screen, convenient to operate...
* Servo film pulling system, Pneumatic horizontal sealing.
* Perfect alarm system to reduce waste;
* It can complete feeding, measuring, filling, sealing, date printing, charging (exhausting), counting, and finished product
delivery when it equips with feeding and measuring equipment;
* The way of bag making: the machine can make pillow-type bag and standing-bevel bag, punch bag or according to customer’s requirements.
* With 3 servo-motor controlled,mechanic horizontal system,The machine is more stable and fast speed than the normal one with pheumatic system controlled.

Main packing machine technical parametes
Model	D-320	D-420	D-520	D-620	D-720	D-820	D-920	D-1200
Bag width(mm)	40-150	60-200	80-250	80-300	100-350	160-400	100-450	200-580
Bag length(mm)	50-200	50-300	80-380	80-450	80-470	90-500	100-570	100-600
Max roll film width(mm)	320	420	520	620	720	820	920	1200
Film material	Heat sealing complex film e.g.OPP/CPP/CE MST/PE/PET,etc.Film thickness::0.04-0.08mm
Packing speed(B/M)	5-80	5-70	5-60	5-50	5-60	5-50	5-40	5-30
Power supply	220V50-60Hz
power	1.5kw	2kw	2.5kw	2.8kw	3.2kw	4.2kw	5.2kw	6.2kw

FAQ

Q: Are you a factory or trading company?
A: We are a factory and manufacturer.

Q: How does your factory do regarding quality control?
A: We pay much attention on quality controlling and strictly follow the Professional standard forms from getting order, parts
procession,assembly for whole set of machine and debug to the shipment.

Q: Where is your factory located? How can I visit there?
A: Our factory located at Guangdong province ,China.You can fly to Guangzhou Baiyun air port.We will arrange to pick you up from
the airport ;it is Around 30 mins from the airport to our factory by car.Or you can take fast Train to Guangzhou from other
countries in China.We will pick you up from the station.

Q: What’s the service and guarantee can you offer?
A: One year guarantee for main parts of machine like PLC,touch screen,ect;Machine installation and worker training service;Free
technical support for lifelong;Material support.
